M15

Magnetic drive pump

  • 2 m³/h
  • 6 mCE
  • 45 W

Guaranteed 100% leakproof thanks to the magnetic drive, these pumps are ideal for transferring the most corrosive fluids.

Guaranteed leakproof

High capacity magnetic coupling

Excellent wear resistance

Ceramic/ceramic or graphite/ceramic bearing

Great performances

Closed centrifugal turbine coupled to a blade diffuser

Improved protection

Built-in strainer

Self-priming

Excentric inlet

Specifications

Hydraulic performances

Flow rate (m³/h)
2
Manometric height (mH2O)
6
Max temperature (°C)
80
Density
1,2

Motor

Power (W)
45
Rotating speed (RPM)
3000
Power supply
230V single phase, 400V three-phase, 230V three-phase
Frequency (Hz)
50 / 60
Standard

Design

Drive
Magnetic
Materials
Polypropylene
Seal
Ceramic/rulon
Seals
EPDM, FPM
Length (mm)
303
Width (mm)
107
Height (mm)
162
